Quad SDI PCIe Video Capture Card 1080P 60FPS A5820
Quad SDI PCIe Video Capture Card 1080P 60FPS A5820
4 SDI inputs support HD-SDI, 3G-SDI, level A&B. Professional video processing function, high-quality industrial-grade chip production, super stability, it supports input of 4 SDI signals simultaneously.
Host interface: PCIE 2.0 X4 20Gb/s transmission bandwidth
Input resolution: any resolution within 1080P
Hardware de-interlacing: Support 1080i hardware de-interlacing, 3D noise reduction algorithm, clearer picture
Operating system support: Windows XP/7/8.1/10 32bit/64bit
Specification of ACASIS Quad SDI PCIe Capture Card
Host interface: PCIE 2.0 X4 20Gb/s transmission bandwidth
Input interface: 4-channel SDI interface
Audio input: 4-channel SDI embedded audio capture
SDI input format: HD-SDI, 3G-SDI
Audio and video capture: Comply with DirectSound specification
Output color space: YUY2
Input resolution: any resolution within 1080P
Hardware de-interlacing: Support 1080i hardware de-interlacing, 3D noise reduction algorithm, clearer picture
Operating system support: Windows XP/7/8.1/10 32bit/64bit
Compatible software: Windows Media Encoder, Adobe Flash Media Live, Encoder, Real Producer Plus, VLC, Wirecast VMIX, etc
Compatible development interface: DirectShow (Windows) standard interface
Operating temperature range: 0-85 degrees Celsius
Package Include
1* Quad SDI Video Capture Card
1*User manual
